STONE3

In stock

STONE3 STONE 3 - ELECTROMECHANICAL PISTON 230V FOR SWING GATES

STONE3 - IS IN PHASE OUT
REPLACED BY THE MODEL : BLADE3

STONE3 / STONE 3 - ELECTROMECHANICAL PISTON 230V FOR SWING GATES
Electromechanical actuators or motor STONE3 is ideal for swing gates up to 5 meters.
Equipped with encoder, release mechanism with coded key, and oscillating rear bracket.
Safe and Precise thanks to the encoder and the slowing down in opening and closing.
Practical thanks to the control unit with plug-in receiver and self-learning function.
Reliable with a sturdy aluminum body treated against oxidation and the oscillating rear
bracket that absorbs the possible sagging of the leafs.

If you are an electrician or automation specialist, call +39.0558778855
or write an email to: commerciale@automazione-cancelli.net
to get a quote/offer and an extra discount

Compare
SKU: TE-STONE3 Categories: , ,

STONE3 STONE 3 – ELECTROMECHANICAL PISTON 230V FOR SWING GATES

STONE3 – IS IN PHASE OUT
REPLACED BY THE MODEL : BLADE3

STONE3 / STONE 3 – ELECTROMECHANICAL PISTON 230V FOR SWING GATES
Electromechanical actuators or motor STONE3 is ideal for swing gates up to 5 meters.
Equipped with encoder, release mechanism with coded key, and oscillating rear bracket.
Safe and Precise thanks to the encoder and the slowing down in opening and closing.
Practical thanks to the control unit with plug-in receiver and self-learning function.
Reliable with a sturdy aluminum body treated against oxidation and the oscillating rear
bracket that absorbs the possible sagging of the leafs.

If you are an electrician or automation specialist, call +39.0558778855
or write an email to: commerciale@automazione-cancelli.net
to get a quote/offer and an extra discount

 STONE3 IT IS REPLACED BY BLADE3
ActuatorS or motor 230 V irreversible electromechanical piston.
For leafs up to 5 m.
STONE3REV  IT IS REPLACED BY BLADE3REV
ActuatorS or motor 230 V reversible electromechanical piston .
For leafs up to 5 m.

TECHNICAL SPECIFICATIONS STONE3 STONE3REV

Motor power supply                                                   230 V
Max. motor current                                                   1,6 A 1,4 A
Motor power                                                             370 VA 330 VA
Thrust                                                                      1600 N 1500N
Max. gate weight                                                       250 Kg
Max opening                                                             120°
Rod stroke                                                               300 mm 500 mm
Actuator speed                                                         19 mm/s 25mm/s
Work cycles                                                             30 % intensive
Capacitor                                                                10 microF
Encoder                                                                  YES
Mechanical limit switches (forseen)                            AP
Grease lubricant                                                      TS10

TECHNICAL SPECIFICATIONS CONTRL UNIT T101/T600
Control unit for 1/2 motors 230 V, MODEL          T101/T600
Power supply                                                   230 V
Max. current                                                    6,3 A
encoder control                                               YES
torque adjustment                                           YES
slowing down.                                                 YES


GENERAL DATA STONE 3
Working temperature                         -20 +55 °C
Protection level                                  IP 44
Weight                                              10 Kg 09 Kg 08Kg
Pallet                                                40 pcs

ACCESSORIES STONE3

ELV
Vertical/horizontal electric lock 12 V.

SERIE OC2
2 channels plug in receiver.

SUPBAT
Pair of brackets to fix 2 BAT12V2a to the cover
of control units box.
BAT12V2A
Battery 12V 2Ah.
CB24
24 V battery charger. Suitable for 24 V control units.

BLA
Leaf stopper.

SRA
Adjustable front bracket. Pack of 2pcs.

SRP
Adjustable rear bracket. Pack of 2pcs.

T600/T101
Control unit for 1/2 motors or actuators STONE3 230 V, with encoder control, torque adjustment and slowing down.
For STONE3 and STONE5.

FC STONE
Mechanical limit switch. Pack of 2 pcs.

SUN POWER
Solar power kit with solar panel and battery.
Suitable for all 24 V control units.

Additional information

Weight 10 kg
Dimensions 1,50 × 0,40 × 0,40 m
