RAP4E

911,00 + TAX

In stock

RAP4E - ELECTROMECHANICAL BARRIERS UP TO 4 M

RAP4E - ELECTROMECHANICAL BARRIER UP TO 4 M
Electromechanical RAP 4E barrier 24 V, with cataphoretic treatment and painting.
With cataphoresis treatment and painting.
Complete with control unit and encoder.
Max boom length 4,25 m. Net span 4 m.

RAP 4E
This barrier has a perfect movement and can operate also in absence of power supply.
This feature thanks to the possibility of inserting 2 back up batteries.<<
Which could be placed in the dedicated housing.
A 24Vdc motor coupled with an encoder ensures perfect controlled boom movement.
The low voltage motor (24 Vdc) allows intensive use in all conditions.
Thanks to the built-in encoder, it provides a high degree of protection against crushing.

If you are an electrician or automation specialist, call +39.0558778855
or write an email to: commerciale@automazione-cancelli.net
to get a quote/offer and an extra discount

Compare
SKU: TE-RAP4E Categories: ,

RAP4E – ELECTROMECHANICAL BARRIERS UP TO 4 M

RAP 4E RAP4E – ELECTROMECHANICAL BARRIER UP TO 4 M
Electromechanical RAP 4E barrier 24 V, with cataphoretic treatment and painting.
With cataphoresis treatment and painting.
Complete with control unit and encoder.
Max boom length 4,25 m. Net span 4 m.

RAP 4E / RAP4E
This barrier has a perfect movement and can operate also in absence of power supply.
This feature thanks to the possibility of inserting 2 back up batteries.<<
Which could be placed in the dedicated housing.
A 24Vdc motor coupled with an encoder ensures perfect controlled boom movement.
The low voltage motor (24 Vdc) allows intensive use in all conditions.
Thanks to the built-in encoder, it provides a high degree of protection against crushing.

If you are an electrician or automation specialist, call +39.0558778855
or write an email to: commerciale@automazione-cancelli.net
to get a quote/offer and an extra discount

RAP4E BARRIER Control unit

The SN24 control electronics of RAP4E / RAP 4E barrier has several stand-out characteristics beginning with
the progressive, calibrated management of the motor power with the possibility
to adjust the manoeuvring speed, the “master/slave” function allowing you to
synchronise two barriers working in unison, internal diagnostics indicating main
errors and the vast array of available command and safety accessories.

The integrated programmer of RAP4E / RAP 4E barrier allows encoder controlled boom positioning, automatic
repositioning and self-programming. The electronic control unit is completed by
the anti-crush and “soft start” and “soft stop” functions.

Open collector:
The product range is factory set for the insertion of an open collector receiver .
Card that guarantees compatibility with all the radio control series available in the
TELCOMA catalogue EDGE NOIRE FM400.

TECHNICAL SPECIFICATIONS RAP4 BARRIER

Motor power supply                                   24 V
Max. motor current                                    5 A
Motor power                                              120 W
Max. torque                                               260 Nm
Max boom length                                      4250 mm
Opening time                                            5,5 sec
Max opening                                             90°
Work cycles                                              50%
Encoder                                                   YES
Limit switches                                           NO
Grease lubricant                                       TS10

TECHNICAL SPECIFICATIONS BUILT IN Control unit
Model                                                      T124R4
Power supply                                           230 V
Max. current                                            1,5 A
Electronic slow down                                YES
Compatible with Sun Power                      YES

GENERAL DATA
Working temperature                               -20 +55 °C
Protection level                                        IP 54
Weight                                                    48 Kg
Pallet                                                      9 pcs

ACCESSORIES RAP4E BARRIER

PSR
Mobile stand for bars.

RAPPER4TL
Asta rigida tubolare in alluminio, verniciata bianca, Ø 7 cm, L 4,25 m, luce netta 4 m.

SRS
Rastrelliera in plastica L 200 cm.

PAF3
Adjustable fixed stand for bars.

FIX RAP4E
Base plate with clamps.

SNR
Joint.

SPB24
External box with 2 batteries 12V 7Ah.
CB24
24 V battery charger. Suitable for 24 V control units.

SUN POWER
Solar power kit with solar panel and battery.
Suitable for all 24 V control units.

LACO24AL
Flashing light 24 V (only lamp) with built in 433 MHz antenna.

SUN POWER
Flashing light 24 V (only lamp) with built in 433 MHz antenna.

NOIREOC2
2 channels plug in receiver NOIREOC2 ROLLING CODE .

EDGEOC2
2 channels plug in receiver NOIREOC2 ROLLING CODE .

FM400OC2
2 channels plug in receiver NOIREOC2 ROLLING CODE .

Additional information

Weight 25 kg
Dimensions 2,00 × 0,60 × 0,40 m
